Description DIN RAIL MOUNTING ADAPTOR FOR PANEL METERS: ATS1 (FOR 96X96MM METERS), ATS2 (96X48MM), ATS3 (72X72MM), ATS4 (48X96MM), ATS5 (48X48MM) Accessories

Description PRODUCT DESCRIPTION Designed for measurement of RMS current and voltage (a.c.), active power and frequency. Thanks to modern design, N27D fulfills the requirements for devices mounted in standard modular switchgears. Features: measurement of: RMS current (a.c.) RMS voltage (a.c.) active power frequency direct measurement up to 63A, switched measured value, 4-digit display in yellow colour, backlighted indicator of measured value, modern design allows for installation of the meter in modular switchgear in accordance with EN 62208 (meter has a width of 3 modules) on 35 mm rail. external dimensions: 53 x 110 x 60mm. SPECIFICATIONS Inputs Kind of input Measuring range Parameters Basic error Voltage input U 0…0.01…1.2 Un input resistance: >3 MΩ ± (0.5% of the range) in frequency range 40…500 Hz Current input I 0…0.01…1.2 In   ± (0.5% of the range) in frequency range 45…65 Hz Voltage frequency 0…2.00…500.0 Hz ± (0.02% of the range)  Current frequency 0…45.00…500.00 Hz   Active power -45.4…-31.5…31.50…45,36 kW at frequency 45… 65 Hz ± (1% of the range) at frequency 45…65 Hz External features       Readout field 4-digit LED displays – digit height: 8.5 mm – yellow,      indication range: -1999…9999       Weight < 0.25 kg     Overall dimensions 53 x 110 x 60 mm  Bezel: 45 ´ 53 mm Protection grade IP00 acc. to EN 60529   Fixing on a 35 mm rail acc. to EN 60715   Rated operations conditions       Supply voltage 230 V ± 10% a.c. (45…65 Hz) Power consumption < 6 VA Input voltage Un 500 V  a.c.  0…2…40.0…500.0 Hz   Input current In 63 A  a.c.  0…45.0…500.0 Hz   Temperature ambient: -10…23…55°C Storage: -25…85°C Relative humidity < 95%  Condensation inadmissible Operating position any   Safety and compatibility requirements Electromagnetic compatibility noise immunity acc. to EN 61000-6-2 noise emissions acc. to EN 61000-6-4 Installation category III up to 300 V  (II for 300…600 V ) Pollution grade 2   Phase-to-earth operating voltage – for the supply circuit: 300 V, – for the measuring input 600 V – category II (300 V – category III) acc. to EN 61010-1

Description PRODUCT DESCRIPTION Designed for direct or indirect measurement of 1-phase network parameters: U, I, f, P, Q, S, PF, tg fi, fi, Ep, Eq. Thanks to modern design, N27P fulfills the requirements for devices mounted in standard modular switchgears. Features: universal measuring input: 1/5 A 100/400 V a.c. 32/63 A, 100/400 V a.c. direct measurement (up to 63A), output: RS-485 interface  with MODBUS protocol, 1 x relay + 1 x analog or 2 x relay, modern graphical display in OLED technology, programmable current and voltage transformer rati os, meter configuration using button or free eCon software (through USB), external dimensions: 53 x 110 x 60mm. SPECIFICATIONS Measured values and ranges Measured Value Range Basic Error Current in   1A 5A 32A* 63A*     0.005>1.200A AC 0.025>6.000A AC 0.160>38.40A AC 0.315>75.60A AC +/- 0.2% Voltage L-N   100V 400V     5>120V 20>480V +/-0.2% Frequency (f) 45.0>66.0>100Hz +/-0.2% Active power (p)   Version – 1/5A Version – 32/63A       -2.88 kvar>1.00 var>2.88 kvar -32.29 kvar>1.00 var>32.29 kvar +/-0.5% Reactive power (Q)   version 1/5A version 32/63A     -2.88 kvar>1.00 var>2.88 kvar -32.29 kvar>1.00 var>32.29 kvar Apparent power (S)   version 1/5 A version 32/63 A     1.40 VA>2.88 kVA 1.40 VA>32.29 kVA PF -1>0>1 Tangensφ -1.2>0>1.2 +/-1% φ 0.359 Active energy (Ep) 0>999 999.9 kWh or 9 999.999 MWh +/-0.5% Reactive energy (Eq) 0>999 999.9 kvarh or 9 999.999 Mvarh *concerns the version for direct measurement   Outputs Output type Description Relay 1-2 x (depending on the meter version) programmable relay output, NOC, load capacity 250 V~/0.5 A~, number of cycles 1 x 10 Analogue lack or 1 x (depending on the meter version) programmable analog output 0/4..20 mA, Rload = 0…250Ω   Digital Interface Interface type Transmission protocol Mode Baud rate RS-485 MODBUS RTU 8N2, 8E1, 8O1, 8N1 4.8; 9.6; 19.2; 38.4; 57.6; 115.2 kbit/s USB1.1/2.0 8N2 9.6 kbit/s   External Features Readout field OLED display   Overall dimensions 53x110x60 mm mounting on a 35mm DIN rail Weight 0.2 kg   Protection grade for housing: IP40 for terminals: IP00   Rated Operating Conditions Power supply 85>253 V a.c. 40…400 Hz / 90>300 V d.c. Power consumpti on: in supply circuit <5 VA in voltage circuit <0.2 VA in current circuit: for undirect meas. <0.05 VA, for direct meas. 40.400A/m   Short duration overload (1s) voltage input: 2 UN (max. 1000 V) current input: 10 IN Sustained overload voltage: 1,2 UN current: 1,2 IN   Safety & Compatability Requirements Electromagnetic compatibility noise immunity acc. to EN 61000-6-2 noise emissions acc. to EN 61000-6-4 Isolati on between circuits basic acc. to EN 61010-1 Polluti on level 2 Installati on category III (for voltages above 300 V – category II) Maximal phase-to-earth working voltage – for supply circuits 300 V – for measuring input 600 V – cat. II (300 V – cat. III) – for other circuits 50 V Altitude above sea level < 2000 m

Description Product Description Disc 2 for autosampler (Required Accessory for Disc 2 for autosampler)

Description Product Description Disc 3 for autosampler (Required Accessory for Disc 3 for autosampler)
