WIRE TRACER LKZ-720 CABLE DETECTOR – Imported, Available Upon Request

Description

SONEL WIRE TRACER LKZ-720 CABLE DETECTOR
The wire tracer LKZ-720 cable detector is designed for detection of wires and cables (live or not) in ceilings,walls and floors. The LKZ-720 cable detector is also used for tracing underground cables, tracing conductive water and heating pipelines. It ensures flow and accurate locating the object as well as phase detection mode.
The wire tracer LKZ-720 cable detector operates in wide range of rated voltage, up to 500 V RMS. There are five modes of wire tracer operation ? voltage, current, current-voltage, power and clamp.
The additional accessories of the LKZ-720 cable detector enables precise localization ? such as contact or non-contact probes and measurement clamp.
With a 3D receiver display, the Sonel LKZ-720 cable detector instrument is suited to finding, tracing, identifying and phasing of all types of building cables, conduits and pipes.
?

?
FEATURES OF WIRE TRACER LKZ-720 CABLE DETECTOR

the function 3D in the receiver ? detecting the direction of current
receiver operation with four transmitters at the same time to locate interruptions or distinguish wires
a LED bright torch
headphone socket in receiver
screens backlight for work in dark
transmission battery status and settings of the transmitter to the receiver
measurement of voltage at the object to 500 V RMS
three levels of transmitter amplification
automatic or manual selection of transmitter operation modes
software upgrade via USB

STANDARD ACCESSORIES FOR LKZ-720 CABLE DETECTOR
The LKZ-720 is supplied ready to use with:

LKN-720 transmitter and? LKO-720 receiver,
test lead with banana plugs; 1 kV; 3.9 ft (1.2 m); red
red crocodile clip 1 kV 20 A
test probe with banana socket;1 kV; red
test lead with banana plugs; 1 kV;3.9 ft (1.2 m); blue
blue crocodile clip 1 kV 20 A
test probe with banana socket;1 kV; blue
test lead with banana plugs on reel; 1 kV; 65.6 ft (20 m); red
earth contact test probe (rod) 0.8 ft (26 cm)
non-contact probe
mini-USB cable

Technical specification for LKZ-720 Cable detector

insulation type:? ? double, acc. to EN 61010-1
transmitter measurement category:? ? III 600 V acc. to EN 61010-1
transmitter ingress protection rating acc. to EN 60529:? ? IP67
receiver ingress protection rating acc. to EN 60529:? ? IP40
transmitter power supply:? ? 4 x AA alkaline batteries or 4 x Ni-MH rechargeable batteries
maximum transmitter operating voltage:? ? 500 V RMS
maximum depth of the analysed object:? ? (?I? mode) 6.6 ft (2 m)
maximum range of contactless neon probe: in air 19.7? (50 cm) and in concrete 2.0? (5 cm)
receiver power supply:? ? 9 V 6LR61 alkaline battery
operating temperature:? ? +14?F?+122?F (-10?C?+50?C)
