T&HLS High And Low Temperature Environmental Testing Equipment Concrete Curing Chamber Climatic Plant Incubation Allschoolabs -

Description

Overview

Essential details

Warranty:: 3 year

Customized support:: OEM, ODM, OBM

Place of Origin:: Jiangsu, China

Brand Name:: T&HLS

Model Number:: TGDW-50T

Power:: Electronic

Product name:: high-low temperature test chamber

Brand:: T&HLS

Temperature Fluctuation:: ≤±0.5℃(standard)

Temperature Evenness:: ≤±2℃

Temperature Deviation:: ≤1°C

Temperature range:: -20℃-150℃

Humidity Devication:: ±2%R.H

Temperature Rise Speed:: 1.0°C~3.0°C/min

Temperature Down Speed:: 0.7°C~1.2°C/min

Certification:: CE,ISO

Supply Ability

Supply Ability: 30 Set/Sets per Month Stability High And Low Temperature Alternating Test Chamber

Packaging & delivery

Packaging Details

Port

Picture Example:

Lead time:

Quantity(sets)	1 – 1	2 – 5	6 – 10	>10
Lead time (days)	25	30	35	To be negotiated

Products Description

Specifications

High -low temperature chamber
	TGDW-100UA	TGDW-150UA	TGDW-250UA	TGDW-500UA	TGDW-010UA
Workroom Dimensions(cm)	*504050*	*505060*	*606070*	*807090*	*100100100*
Inner chamber volume(v)	100L	150L	252L	504L	1000L
*Outer Diemension WDH(cm)*	*9895160*	*98105170*	*108112180*	*128125200*	*148155210*
Packing Size	*113110175*	*113120185*	*123127195*	*133140215*	*163160225*
G.W(kg)	340	370	430	460	600
Temperature Range	A:-20℃-150℃ B:-40℃-150℃ C:-60℃-150℃ D:-80℃-150℃
TemperatureFluctuation	≤ ±0.5℃ (standard)
Temperature Evenness	≤ ±2℃
Temperature Deviation	≤ 1℃
Accuracy	0.1℃ (standard)
Temperature Rise Speed	1.0℃~3.0℃/min
Temperature Down Speed	0.7℃~1.2℃/min
Time needed for heating	RT℃~150℃≤30min
Time needed for cooling	RT℃~-40℃≤30min
The machine noise	≤72dB(A)
Load on the largest	100kg,≤20 kg/layer	150kg,≤26 kg/layer	260kg,≤30 kg/layer	260kg,≤40 kg/layer	300kg,≤60 kg/layer
Equipment installed power	~1.95KW	~2.35KW	~2.85KW	~3.5KW	~4.35KW
Material	The studio:# SUS304 stainless steel			The outer wall:A3 carbon steel plate with plastic spray/ #SUS304
Wind Cycling Way	Centrifugal fan-broadband type forced air ciruculation
Refrigeration Way	Single stage compression refrigeration
Refrigerater	French Tecumseh
Refrigerats	R404A USA Dupont environment protection refrigerant
Condesing Way	Air-cooled or water-cooled
Heater	Nickel Chorme Heating Wire Heater
Control Instrument	HLS touch screen
Design Criteria	GJB150.3 GJB150.4 GB/T2423.22 GB10589-89 GB11158-89
Standard Accessories parts	Observe window(double-deck cavity toughened glass),PL inner chamber,Wet and dry bull gauze, 3 fues, 1 power line

Company Profile

FAQ

Q 1: Are you manufacturer?
A: Yes, we are manufacturer with more than 10 years’ experience.
Q 2:  What are your Price Terms?
A  : Price can be based on FOB, CFR, or CIF, etc.
Q 3: What are your Payment Terms?
A: Payment shall be made by T/T, L/C, or D/P, etc., it varies considerably according to the region that you are in.
Q4: What’s your Minimum Order Quantity?
A: Any order quantity is warmly welcomed.
Q 5: Do you have English Manual for each machinery?
A: Yes. The instruction manual,the test report and other Data Sheets related shall be provided by us.
Q 6: Can I print my Logo on the machine?
A: Yes, sure.
Q 7: Can you customize the machine for me ?
A: Yes, we can customize according to customer’s requirements.
Q 8: What shall we do if breakdown occurs?
A: Please informed us once the breakdown occurs. During warranty period, if breakdown occurs, we shall respond in time after receiving the notification of the buyer. We shall handle failure over the telephone/ fax or arrange relevant personnel to the site according to the buyer’s requirements.
Q 9: What are your modes of transportation?
A: Courier service, Air transport, Sea Transport.
Q 10: Which ports do you usually ship at?
A: We can load container at: Qingdao, Shanghai, Ningbo, Tianjin, Guangzhou etc.
Q11: Do you support overseas installtion and debugging?
A: Yes, normally We will despatch a profesional team with translater to the field to complete the whole project.
Q12: If any breakdown, do you have any prompt ways to support us?
A: Yes, we have on-line services to make one-one explanation.
