Main
product or component type
Power socket-outlet
load type
Resistive
cover frame colour tint
Silver bronze
cover plate colour tint
Bronze
Complementary
device mounting
Surface
Flush
local signalling
Mechanical indicator (amber)
switch function
1-pole
rated current
13 A at 250 V AC 50 Hz
number of gangs
1 gang
material
Brass contact
Phosphor contact
Polycarbonate base
Polycarbonate grid plate
Polycarbonate surround
connections ? terminals
Folded terminal
width
87?mm
height
87?mm
depth
8?mm
Main
product or component type
Power socket-outlet
outlet poles configuration
2P
load type
Resistive
colour tint
White
cover frame colour tint
White
Complementary
device mounting
Surface
Flush
local signalling
Mechanical indicator (amber)
rated current
13 A at 250 V AC 50 Hz
number of gangs
1 gang
material
Brass contact
Phosphor contact
Polycarbonate base
Polycarbonate grid plate
Polycarbonate surround
connections ? terminals
Folded terminal
width
87?mm
height
87?mm
depth
8?mm
Ultra-thin and streamlined design with 8mm thickness. The electric gap is bigger than 3mm, greatly improves the safety. A new structure design of socket brings convenience and comfortability. Full ranges of British Standard socket.
Main
product or component type
Socket-outlet
device short name
KB426
device presentation
Complete mechanism
outlet standard
Universal
Colour tint
White
Complementary
outlet poles configuration
2P + E
number of gangs
1 gang
material
Polycarbonate: grid plate
Polycarbonate: surround
Nylon: base
projecting depth
8?mm
device mounting
Flush
mounting support
Wall mounted
fixing mode
By screw M3.5
fixing center
60.3 mm
embedding depth
35?mm
rated current
13 A at 250 V AC, no inductive load
network frequency
50 Hz
contacts material
Brass and phosphor bronze
connections ? terminals
Pillar terminal
terminal identifier
L
N
E
tightening torque
0.4?N.m
clamping connection capacity
2.5 mm?
4 mm?
width
86?mm
height
86?mm
Main
range
Vivace
product or component type
Socket-outlet with switch
device short name
KB15
device presentation
Complete mechanism
Complementary
outlet poles configuration
2P + E
number of gangs
1 gang
Colour tint
White
material
Polycarbonate: grid plate
Polycarbonate: surround
Polycarbonate: base
projecting depth
8?mm
device mounting
Flush
mounting support
Wall mounted
fixing mode
By screw M3.5
fixing center
60.3 mm
embedding depth
35?mm
rated current
13 A at 250 V AC, resistive
network frequency
50 Hz
contacts material
Brass and phosphor bronze
connections ? terminals
Pillar terminal
terminal identifier
N
Earth
L
tightening torque
0.4?N.m
clamping connection capacity
2 x 4 mm?
3 x 2.5 mm?
width
87?mm
height
87?mm
Main
range
Vivace
product or component type
Socket-outlet with switch
device short name
KB15
device presentation
Complete mechanism
Complementary
pilot light
Red neon indicator
outlet poles configuration
2P + E
number of gangs
1 gang
Colour tint
White
material
Polycarbonate: grid plate
Polycarbonate: surround
Polycarbonate: base
projecting depth
8?mm
device mounting
Flush
mounting support
Wall mounted
fixing mode
By screw M3.5
fixing center
60.3 mm
embedding depth
35?mm
rated current
13 A at 250 V AC, resistive
network frequency
50 Hz
contacts material
Brass and phosphor bronze
connections ? terminals
Pillar terminal
terminal identifier
N
L
Earth
tightening torque
0.4?N.m
clamping connection capacity
2 x 4 mm?
3 x 2.5 mm?
width
87?mm
height
87?mm
Main
range
Vivace
product or component type
Socket-outlet
device application
Power supply
Colour tint
White
Complementary
number of gangs
2 gangs
rated current
13 A at 250 V AC
Main
range
Vivace
product or component type
Socket-outlet with switch
device short name
KB25
device presentation
Complete mechanism
Complementary
outlet poles configuration
2P + E
number of gangs
2 gangs
Colour tint
White
material
Polycarbonate: grid plate
Polycarbonate: surround
Polycarbonate: base
projecting depth
8?mm
device mounting
Flush
mounting support
Wall mounted
fixing mode
By screw M3.5
fixing center
120.6 mm
embedding depth
35?mm
rated current
13 A at 250 V AC, resistive
network frequency
50 Hz
contacts material
Brass and phosphor bronze
connections ? terminals
Pillar terminal
terminal identifier
L
N
Earth
tightening torque
0.4?N.m
clamping connection capacity
3 x 2.5 mm?
2 x 4 mm?
width
147?mm
height
87?mm
Main
range
Vivace
product or component type
Socket-outlet with switch
device short name
KB25
device presentation
Complete mechanism
Complementary
pilot light
Red neon indicator
outlet poles configuration
2P + E
number of gangs
2 gangs
Colour tint
White
material
Polycarbonate: grid plate
Polycarbonate: surround
Polycarbonate: base
projecting depth
8?mm
device mounting
Flush
mounting support
Wall mounted
fixing mode
By screw M3.5
fixing center
120.6 mm
embedding depth
35?mm
rated current
13 A at 250 V AC, resistive
network frequency
50 Hz
contacts material
Brass and phosphor bronze
connections ? terminals
Pillar terminal
terminal identifier
L
N
Earth
tightening torque
0.4?N.m
clamping connection capacity
2 x 4 mm?
3 x 2.5 mm?
width
147?mm
height
87?mm
