STRUCTURE FEATURES

MSB series pump is single-stage centrifugal pump and features axial suction and radial discharge
Compact structure, the pump is directly connected with the motor, coaxial installation
Convenient installation, screw thread water inlet and outlet
Light weight, thin plate pressing structure for main parts and components
Corrosion resistance, components passing the flow use AISI 304 or AISI 316 stainless steel.

APPLICATION

Pressurization and pumping of industrial and civilian water or other liquids
Water treatment
Water circulating system
Agricultural irrigation
Other fields

OPERATING CONDITION

Lquid temperture: -100C – +850C
Ambient temperature: up to +400C
Altitude: up to 1000m
Max. pressure of the system is 8bar
Rated flow: 250(L/min)
Rated power: 1.5HP

MOTOR

TEFC motor, 2-pole
Protection class: IP55
Insulation class: F
Standard voltage: 50Hz 1x220V, 3x380V/3x220V
