Effective volume (L) |
Dimension of tank (mmxmm) |
Total height (mm) |
Motor power (kw) | Diameter of inter &outlet(mm) | Heat preservation layer(mm) |
Blending speed (r/min) |
| 1000 | 1060*1220 | 2500 | 1.1 | 51 | 60 | Common rotation speed 35, 43, 60 r/min. Stepless speed reducer or dual speed reducer are also available. |
| 1500 | 1160*1500 | 2850 | 1.1 | 51 | 60 | |
| 2000 | 1340*1500 | 2900 | 1.1 | 51 | 60 | |
| 3000 | 1410*2000 | 3400 | 1.5 | 51 | 60 | |
| 4000 | 1620*2000 | 3450 | 1.5 | 51 | 60 | |
| 5000 | 1810*2000 | 3500 | 2.2 | 51 | 60 | |
| 6000 | 1980*2000 | 3550 | 2.2 | 51 | 60 | |
| 7000 | 1930*2440 | 4000 | 3 | 51 | 60 | |
| 8000 | 2060*2440 | 4000 | 3 | 51 | 60 | |
| 9000 | 2180*2440 | 4050 | 4 | 51 | 60 | |
| 10000 | 2300*2440 | 4050 | 4 | 51 | 60 | |
| 12000 | 2270*3000 | 4600 | 5.5 | 51 | 60 | |
| 15000 | 2530*3000 | 4700 | 5.5 | 51 | 60 | |
| 20000 | 2640*3660 | 5400 | 5.5 | 51 | 60 |
Q: How long have you worked in this field?
A: Over 15 years.
Q:What’s the delivery time?
A: Standard products will be 10-15days after receive your down payment or full payment.
Q: Can your factory produce products according to our drawings or samples?
A: Yes, of course we can.
Q: Are you manufacturer or trading company ?
A: We are a professional manufacturer.
Q: What is your factory’s biggest advantage?
A: Technology is our core competitiveness.
