Overview
Essential details
- Warranty:
-
1.5 years, 1.5 years
- Customized support:
-
OEM, ODM
- Place of Origin:
-
Henan, China
- Brand Name:
-
CY-MACH
- Model Number:
-
CY – 300
- Power:
-
Electronic
- Product name:
-
Standard laboratory test sieve shaker with 1-9 layer sieve screen
- Condition:
-
New
- Type:
-
Circular
- Keyword:
-
Round Vibration Test Screen
- Function:
-
Particle Size Analysis
- Size:
-
1-800 mesh
- Weight:
-
40kg
- Accuracy:
-
95%
- Feature:
-
Multi-layer, simple operation
Supply Ability
- Supply Ability
- 50 Set/Sets per Week Standard laboratory test sieve shaker with 1-9 layer sieve
Packaging & delivery
- Packaging Details
Standard laboratory test sieve shaker with 1-9 layer sieve screen
Standard wooden case package
- Port
Qingdao, Tianjin, Shanghai or As client’s demand
- Picture Example:
-
- Lead time:
-
Quantity(sets) 1 – 1 >1 Lead time (days) 5 To be negotiated
Product Display
All laboratory analysis equipment work with an vibration motor drive. This drive produces a 3 D throwing motion that moves the material to be sieved equally over the whole sieving surface.
Multi-layer standard lab analysis test sieve with timer is a new and precision equipment for continuously selecting / sifting / testing the powder. It uses the new type vibrating motor as the source of vibration. It is usually equipped with Φ 100 mm, Φ 200 mm standard sieve, standard sieve and Φ 300 mm standard sieve. We can also produce the test sieve according to the customer’s requirements.
Multi-layer standard lab analysis test sieve with timer is a new and precision equipment for continuously selecting / sifting / testing the powder. It uses the new type vibrating motor as the source of vibration. It is usually equipped with Φ 100 mm, Φ 200 mm standard sieve, standard sieve and Φ 300 mm standard sieve. We can also produce the test sieve according to the customer’s requirements.
Product Paramenters
|
Items
|
Name
|
Unit
|
Data
|
|
1
|
Layers
|
layer
|
1-8
|
|
2
|
Diameter
|
mm
|
200, 300
|
|
3
|
Sieve frame
|
mm
|
100, 200, 300, 400
|
|
4
|
Noise
|
db
|
below 50
|
|
5
|
Feeding Capacity (Once)
|
g
|
<200 g/ml
|
|
6
|
Amplitude
|
mm
|
<5
|
|
7
|
Voltage
|
v
|
220 v / customized
|
|
8
|
Power
|
kw
|
0.125
|
|
9
|
Overall Dimension
|
mm
|
450*410*700
|
|
10
|
Weight
|
kg
|
45
|
Products Description
1.The machine has the function of re-crashing the agglomeration materials and is safe and reliable for a long time operation
2.The screen machine can be placed a maximum eight layers tests sieves (including the bottom sieve), can separate the material into 2 to 7 grade at the same time
3.The products can be automatic shut down according to the electric time controller and accurate judgement of the online product quality
4.These machines are suitable for both wet and dry sieving, and meet all ergonomic requirements for a modern laboratory.
5.Free adjustment of all process parameters (time, amplitude).
2.The screen machine can be placed a maximum eight layers tests sieves (including the bottom sieve), can separate the material into 2 to 7 grade at the same time
3.The products can be automatic shut down according to the electric time controller and accurate judgement of the online product quality
4.These machines are suitable for both wet and dry sieving, and meet all ergonomic requirements for a modern laboratory.
5.Free adjustment of all process parameters (time, amplitude).
Product packaging
Company Profile
Our Service
FAQ
Pls confirm and provide below information to us before making an exact solution and price for you for Automatic analysis lab test sieve shaker.
Q: What information do I need to provide us to getting an accurate quotation for Standard laboratory test sieve shaker machine?
1. Your material’s name, bulk density, and water content.
2. How many layers are you need? And what’s the screen mesh size for each layer?
3. Voltage and frequency.
Q: How long for the delivery time?
A: 5-10 working days for conventional products.
Q: How long for warranty time?
A: 18 months from the shipping date.
Q: What information do I need to provide us to getting an accurate quotation for Standard laboratory test sieve shaker machine?
1. Your material’s name, bulk density, and water content.
2. How many layers are you need? And what’s the screen mesh size for each layer?
3. Voltage and frequency.
Q: How long for the delivery time?
A: 5-10 working days for conventional products.
Q: How long for warranty time?
A: 18 months from the shipping date.
