Double Softening System WAT
For continuous production of softened water. Thermo Scientific™ Double Softening System WAT includes a hardness sensor control that automatically regenerates resin once hardness is detected in one of the two cartridges. This ready-to-connect water softener is for softening feed water before feeding a reverse osmosis system. Water softening removes hard ions, such as calcium and magnesium, and extends the life of the reverse osmosis membrane.
Twin softening systems with hard water sensor (1in.)

Twin softening systems with hard water sensor
Sensor initiates one of two cartridges to automatically regenerate
Features include error messages and automatic switch off (LED lights)
Potential free contact for connection to a central fault collector, which allows the system to be connected to the users central error collection monitor
Water connections are R 1 in.
230V/50Hz

Twin softening system with hard water sensor (2 in.)

Twin softening systems with hard water sensor
Sensor initiates one of two cartridges to automatically regenerate
Top mounted with inlet and outlet pipe bridge fitted with automatic switchover and electronic sensor control, making the system easier to install
Fault-triggered switch off with hard water as well as signal output and potential free contact for fault messages — If error isn’t addressed, system will automatically turn off
Connector for solenoid or membrane valve
Glass-fiber pressure container
Brass automatic valve with 4-stage regeneration procedure
Water connections are R2 in.
230V/50Hz
