High And Low Temperature Environmental Climate Test Equipment
High And Low Temperature Environmental Climate Test Equipment
Application:
Programmable High And Low Temperature Environmental Climate Test Equipment is also called environment testing machine, used to test various types of materials for their tolerances of heat, cold, dry, humidity. It is applied for quality inspection for all types of electronic products, electric appliance, and products from communication, instrument, automobile, plastic, metal, food, chemical, building materials, medical and aerospace industries.
Temperature Humidity Chamber Technical Parameters:
|
Model |
TH-80(A~F) |
TH-150(A~F) |
TH-225(A~F) |
TH-408(A~F) |
TH-800(A~F) |
TH-1000(A~F) |
|
|
Internal Dimension WxHxD (mm) |
400x500x400 |
500x600x500 |
600x750x500 |
600x850x800 |
1000x1000x800 |
1000x1000x1000 |
|
|
External Dimension WxHxD (cm) |
950x1650x950 |
1050x1750x1050 |
1200x1900x1150 |
1200x1950x1350 |
1600x2000x1450 |
1600x2100x1450 |
|
|
Temperature Range |
Low Temperature(A:25°C B:0°C C:-20°C D:-40°C E:-60°C F:-70°C) High Temperature 150°C |
||||||
|
Humidity Range |
20%~98%R.H.(10%-98% R.H. / 5%-98% R.H ,is optiona , need Dehumidifier) |
||||||
|
Indication relolution/ Distribution uniformity of temperature and humidity |
0.1°C; 0.1% R.H/±2.0°C; ±3.0% R.H. |
||||||
|
Indication relolution/ Distribution uniformity of temperature and humidity |
±0.5°C; ±2.5% R.H. |
||||||
|
Temperature Rising / Falling Velocity |
Temperature rising approx. 0.1~3.0°C/min |
||||||
|
Inner and Outer Material |
Interior material is SUS 304# stainless steel, exterior is stainless steel or see cold-rolled steel with paint coated. | ||||||
|
Insulation Material |
Resistant to high temperature, high density, formate chlorine, ethyl acetum foam insulation materials |
||||||
|
Cooling System |
Wind cooling or water cooling, (single segment compressor-40°C, double segment compressor -70°C) |
||||||
|
Protection Devices |
Fuse-free switch, overloading protection switch for compressor, high and low voltage coolant protection switch, over-humidity and over-temperature protection switch, fuses, fault warning system, water short storage warning protection |
||||||
|
Optional Accessories |
Inner door with operation hole , Recorder, Water Purifier, Dehumidifier |
||||||
|
Compressor |
French Tecumseh Brand, Germany Bizer Brand |
||||||
|
Power |
AC220V 1 3 lines, 50/60HZ , AC380V 3 5 lines , 50/60HZ |
||||||
|
Approx. Weight (Kg) |
150 |
180 |
250 |
320 |
400 |
450 |
|
Hot and Cold Impact Testing Machine Features:
1. Graceful appearance, circularly shaped body, surface treated with mist strips . Easy to operate, safe and reliable.
2. Rectangular double-paned viewing window for viewing sample under test, with interior light
3. Double-layer-insulated airtight doors, able to insulate the internal temperature effectively.
4. Water supply system that is externally connectable, convenient for refilling water into the humidifying pot and automatically recyclable.
5.French Tecumseh is used as compressor, with environment friendly refrigeration R23 or R404A
6. LCD display screen, capable of displaying the measured value as well as the set value and time.
7. The control unit has the functions of multiples segment program editing, with quick or ramp rates control of temperature and humidity.
8. Casters are provided for ease of mobility, with strong positioning screws.
Customers’ Visit ASLi Factory:
Package: PP film first, and then 10mm foam between machine and the case, and outside is standard export plywood case.
Shipping Detail:
Short introduction about ASLi factory:
We are a long history testing equipment manufacturer, in the past 28 years, we devoted to simulation environmental testing equipment and Mechannical vibration and shock testing machine. find complete details about High And Low Temperature Environmental Climate Test Equipment is our star products , and we had obtained the CE certification for this machine .
ASLi main test equipments:
Environmental chambers, temperature (humidity) chamber,Thermal shock chamber, PCT /Hast chamber (Highly accelerated stress test chamber),ESS chamber, Walk in stability chamber,Vacuum oven,electrodynamic vibration shaker,mechanical shock tester,environmental combined vibration chamber,etc
1. Are your company a trading one or a factory?
Factory ,28 years focusing on test instruments field,4 years exporting experience.
2. After an order is placed, when to deliver?
Generally about 20 days, If we have finished products, we can arrange shipment within 3 days.
Please be aware that our production lead times depend on specific items and item quantities.
3. What about the warranty with after – sales services?
12 months warranty.
After the warranty, the professional after-sale service team will provide perfect technical support,and help customer solve problems encountered while using our product, handles guest problems and complaints in a professional and timely.
4. What about the services and product’ quality?
Each instruments must be carried out 100% quality examination and test, the finished products must through a third party calibration institutions before shipping and delivery goods.
If you need more information about High And Low Temperature Environmental Climate Test Equipment , please don’t hesitate to send your inquiry.
