?General
?–128 arrays, 32 transmitting and receiving channels
?–Scanning mode: Convex/linear/micro-convex
?–Imaging mode: B, B+B, 4B, B+M, M
?–Transducer connector: 2 (standard)
?–Scanning depth: 40-250(depending on transducer)
?–Cine-loop: 2000 frames, several frames(B, 2B, 4B, 9B) can played simultaneously, also support B/M, M mode
?–Image conversion: Up/down, left/right, black/white
?–8 segment TGC adjustment, Gamma correction, Stat, Histogram,
?–Probe selectable: Convex, linear, micro-convex, transvaginal, rectum

?Display:
?–10 inch B/W SVGA monitor
?–Display: Date, time, name, sex, age, doctor, hospital, annotation, probe name, probe fequency, measurement values, body marks etc.

?Standard configuration:
?R60/3.5MHz convex(2.5/3.5/6.0MHz)
?10 inch B/W SVGA monitor, USB2.0 port

?Optional:
?– R13/6.5MHz Transvaginal concex(5.0/6.5/8.0MHz)
?– R20/5.0MHz Micro-convex(2.5/3.5/6.0MHz)
?– 7.5MHz Linear(6.5/7.5/12.0MHz)
?– 6.5MHz Rectum Linear(5.0/6.5/8.0MHz)
?– ink jet printer, laser printer, video printer, video recorder
?– trolley, puncture frame

?Size & Weight:
?N. W.: 11.5KG (inc. One probe) G. W.: 13.5KG
?Dimensions: 355mm(W)x315mm(L)x255mm(H)
?Meas: 425mm(W)x395mm(L)x410mm(H)

?Power Supply:
?AC: 100V-115V/220V-240V, 50/60H
?
