Brand : Airliquide Medical
Model : Monnal T75

Specification of Air Liquide Monnal T75:
BrandAir LiquideModelMonnal T75Ventilation ModesVCV, PCV, SIMV, PSIMV, PSV, PRVC, PSV-NIV, APRV, CPAP, NIV in all barometric modes, PS Pro, Duo-leveRespiratory RateRR (5 to 100 bpm)RSBI (Rapid Shallow Breathing Index)yesPatient Age GroupAdult, PaediatricPlateau (%)0-60%Patient RangeAdult,Child,InfantPatient Weight3 to 250 kg / 20 to 2,000 mlFeatures of Air liquide Monnal T75:

Monnal T75 Feature :

For Invasive and non-invasive ventilation, as well as high flow oxygen therapy.
Monnal T75 high performance and versatile ventilator. Its compact, mobile design and built-in power source fulfil patient and health care staff requirements.

Monnal T75 is quick, convenient and safe to operate, making it ideal for a wide range of health care use. :

? Patient range Adult, child, infant

? Patient weight 3 to 250 kg / 20 to 2,000 ml
Main parameters :

? Vt (20 to 2,000 ml), RR (4 to 120 Bpm), PI (2 to 99 cm H2O), PS (2 to 40 cm H2O), Vpeak (180 l/min)

? Invasive ventilation modes : VCV, PCV, PRVC, SIMV, PSIMV, PSV, CPAP, PS-Pro, Duo-Levels

? Non invasive ventilation modes PSV, CPAP, Duo-Levels, APRV
Performance :

? From intermediate to critical care

? Synchronization and pressurization quality in invasive and non-invasive ventilation

? Wide range of ventilation modes including PSV, Duo-Levelsn APRV, high-flow oxygen therapy function, PS-Pro
Versatility:

? Patients from newborns to adults

? Air and power supply autonomy

? Optimized mobility
Monitoring:

? Automatic compliance and resistance measurement

? Complete capnography including EtCO2, VMCO2, VMalv, VDaw

? Weaning index: P0.1, NIF, WOBI
Monnal Clean’In : Monnal Clean’In is a filter which guarantee the purity of the air breathed by the patient.

? An HEPA (High Efficiency Particulate Air) filter taht filters 99.97% of the particules

? Fully integrated into the ventilator

? Easy to handle
PS-Pro Mode :

PS-Pro is a unique mode specifically designed to assist patient recovery. Its self-adapting behavior offers safe, continuous and confortable ventilation.
Using PS-Pro medical staffs are free to focus more on delivering care to the patient.

Ventilator with Trolley?
Inbuilt Turbine ( No air source required )?
Optional : Humidifier
